| Place of Origin: | CHINA |
| Brand Name: | EYESKY |
| Certification: | CE，ROSH，FCC，SIL |
| Model Number: | ES60A |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD500-1500 |
| Delivery Time: | 2-3DAYs |
| Payment Terms: | L/C, D/A, T/T, Western Union, MoneyGram |
| Precision: | ≤±3%FS | Alarm Mode: | Audible-visual Alarm，Vibration Alarm，Voice≥75dB@25cm; |
|---|---|---|---|
| Preheat Time: | ≤90s | Response Time: | T90≤30s |
| Recovery Time: | ≤20s | Explosion Proof Grade: | Ex Ib IIB T3 |
| Protection Grade: | IP66 | ||
| High Light: | 4 in 1 gas detector,gas testing equipment |
||
Product features:
Portable 6 in 1 gas detector used to detect the gas concentration in many applications, including of the chemical industry, petroleum, gas station, metallurgy, agriculture, biology pharmaceuticals, power, lab research and other industry environment where need to inspect combustible or toxic gas concentration.
The Portable 4 in 1 gas detector with the LED light, it’s very convenient for the underground usage, such as the Mine, Coal Mine, Tunnel, etc.
Features of Portable 6 in 1 gas detector:
Original imported sensor with high performance and precision, good stability and repeatability, long working time.
TFT LCD screen display the measuring data.
Record the alarm data of 10,000 sets.
With the 32bit low power consumption ARM processor and quick response.
Restore factory setting function, avoid the mis-operation.
Three alarm mode: Audible, Visual, Vibration.
Support for 4 sensor at the same time.
Support the Chinese/English language menu.
The menu interface with words and icon.
Explosion-proof grade of Ex ib IIB T3 Gb；
Protect grade of IP65.
| Item | Description |
| Gas type: | Ex,O2,CO,H2S,voc,o3 or customized; |
| Working principle: |
Catalytic combustion sensor for combustible gas; Electrochemical sensor for toxic gas and oxygen. |
| Testing mode: | Diffusion sampling. |
| Display mode: | TFT LCD display |
| Concentration Unit: | %VOL,%LEL,ppm,mg/m3; |
| Measuring range: |
EX:0-100%LEL； O2:0-30%VOL CO:0-500ppm H2S:0-100ppm voc:0-1000ppm o3:0-100ppm ; or customized; |
| Resolution: |
EX:1%LEL； O2:0.1%VOL CO:1ppm H2S:1ppm voc:1ppm o3:1ppm ; or customized; |
| Precision: | ≤±3%FS; |
| Alarm mode: | Audible-visual alarm,Vibration alarm,Voice≥75dB@25cm; |
| Preheat time: | ≤90s; |
| Response time: | T90≤30s; |
| Recovery time: | ≤20s; |
| Explosion proof grade: | Ex ib IIB T3; |
| Protection grade: | IP66; |
| Output signal: | Wireless transmission and print function(Optional); |
| Body material: | PC+TPU; |
| Working temperature: | -20℃～+50℃(or customized); |
| Working humidity: | ≤95%RH,(non-condensing); |
| Charger: | USB port; |
| Working voltage: | 3.7V rechargeable lithium battery; |
| Charging time: | ≤6 hours; |
| Working time: | ＞8hours continuously(When normal temperature and no alarm); |
| Power consumption: | <0.7W; |
| Working pressure: | 86～106KPa; |
| Dimension: | 119.6x60x44mm(L*W*H); |
| Weight: | About 182g; |
| Standards: | GB3836.1-2010,GB3836.2-2010,GB3836.4-2010,MT 704-2008, MT 703-2008,MT 1084-2008,GB 15322.3-2003; |
| Warranty: | 12 months; |
| Accessory: | Box, instruction, USB charger , data line, calibration cap. |
