Carbon Dioxide 3.7V Lithium Battery Single Gas Detector

Carbon Dioxide 3.7V Lithium Battery Single Gas Detector

  • Carbon Dioxide 3.7V Lithium Battery Single Gas Detector
  • Carbon Dioxide 3.7V Lithium Battery Single Gas Detector
  • Carbon Dioxide 3.7V Lithium Battery Single Gas Detector
  • Carbon Dioxide 3.7V Lithium Battery Single Gas Detector
  • Carbon Dioxide 3.7V Lithium Battery Single Gas Detector
Carbon Dioxide 3.7V Lithium Battery Single Gas Detector
Product Details:
Place of Origin: CHINA
Brand Name: EYESKY
Certification: CE,FCC,SIL,ROSH
Model Number: ES30A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 150-500USD
Packaging Details: carton packaging
Delivery Time: 3-5 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 sets per year
Contact Now
Detailed Product Description
Display: Custom LCD Measuring Range: 0 ~ 100% LEL / 0-100ppm (optional For Other Ranges)
Operating Temperature: -20°C To +50°C (-4°F To 122°F) Zero Drift: ≤±1%(F.S/Year)
High Light:

IP66 Carbon Dioxide Gas Detector

,

0.7W Natural Gas Detector



ItemDescription
Gas type:CO or customized;
Working principle:Catalytic combustion sensor for combustible gas;
Electrochemical sensor for toxic gas and oxygen.
Testing mode:Diffusion sampling.
Display mode:TFT LCD display
Concentration Unit:ppm
Measuring range:0-500ppm or customized;
Resolution:1ppm
Precision:≤±3%FS;
Alarm mode:Audible-visual alarm,Vibration alarm,Voice≥75dB@25cm;
Preheat time:≤90s;
Response time:T90≤30s;
Recovery time:≤20s;
Explosion proof grade:Ex ib IIB T3;
Protection grade:IP64;
Output signal:Wireless transmission and print function(Optional);
Body material:PC+TPU;
Working temperature:-20℃~+50℃(or customized);
Working humidity:≤95%RH,(non-condensing);
Charger:USB port;
Working voltage:3.7V rechargeable lithium battery;
Charging time:≤6 hours;
Working time:>8hours continuously(When normal temperature and no alarm);
Power consumption:<0.7W;
Working pressure:86~106KPa;
Dimension:119.6x60x66mm(L*W*H);
Weight:About 182g;
Warranty:12 months;
Accessory:Box, instruction, USB charger , data line, calibration cap.


 Carbon Dioxide 3.7V Lithium Battery Single Gas Detector 0Carbon Dioxide 3.7V Lithium Battery Single Gas Detector 1Carbon Dioxide 3.7V Lithium Battery Single Gas Detector 2Carbon Dioxide 3.7V Lithium Battery Single Gas Detector 3
Portable gas detector used to detect the 6 kinds of gases at the same time, high accurate and fast response , it’s easy to operate and with the LED light very convenient to use in the underground ,such as mine, coal mine and tunnel, will send out the alarm signal once the concentration of detect gas is exceed immediately , protect the constructing worker’s health and remind them to leave to the safe place. gas detector applied for many industrial areas , including of the chemical industry, petroleum, gas station, metallurgy, coal mine, agriculture, biology pharmaceuticals, power, lab research and other industry environment
Features of Portable gas detector:
Imported sensor with high performance and fast response
TFT LCD screen display with LED light.
Record the alarm data of 10,000 sets.
Can set high and low alarm value
With the 32bit low power consumption ARM processor and quick response.
Restore factory setting function, avoid the mis-operation.
Three alarm mode: Audible, Visual, Vibration.
Support for 6 sensors detecting
Support the Chinese/English language menu.
The menu interface with words and icon.
LED light function, can provide the light in the dark area or other Emergency time.
LED indicate light, will flash in the dark area.
USB charger port.
Explosion-proof grade of Ex ib IIB T3 Gb;
Protect grade of IP64.


Gas typeMeasuring range
Ex0~100%LEL
O20~25%vol/30%vol
H2S0~100ppm/1000ppm
H20~1000ppm/60000ppm
N20~100%vol
NH30~100ppm/500ppm
C2H6O0~100ppm/500ppm
SO20~20ppm/2000ppm
Cl20~10ppm/20ppm/50ppm/200ppm
HCl0~50ppm/100ppm
HBr0~50ppm/100ppm
ClO20~50ppm
NO0~200ppm/500ppm/2000ppm
NO20~20ppm/100ppm/500ppm/2000ppm
HCN0~30ppm/50ppm/100ppm
HF0~10ppm
CH2O0~10ppm
THT0~50mg/m3
Helim0~1000ppm
Argon0~100%vol
SiH60~50ppm/100ppm
CH6S0~20ppm
CO20~5000ppm/10000ppm
SF60~1000ppm
CH60~200ppm/10%vol
TVOC0~20ppm/100ppm/1000ppm
CS20~10ppm/50ppm/100ppm
CH3Br0~20ppm/100ppm/200ppm
CH60~10%vol/50%vol/100%vol
